HRE Series
Slurry submersible pumps are designed for pumping liquid containing solids and abrasive particles. Slurry pump changes in design and construction to adjust to multiple type of slurry which varies in concentration of solids, size of solid particles, shape of solid particles, and composition of solution. Dynamically balanced Hi-Chrome impellers are used for reliable operation which is basically white iron with 25% chromium added to make it less brittle. Slurry pumps are widely used in transport of abrasive solids in industries such as mining, dredging, power and steel.
Maximum Flow | upto 150m³/h |
Head | upto 42m |
Speed | 2900 RPM |
Impeller Type | Semi open / Enclosed Impeller |
Outlet Size | upto 100mm |
Power | upto 10kW |
Liquid Temperature | upto 40°C |
Max Solid Size | upto 10mm |
Shaft Seal | Mechanical Seal |
Material of Construction (MOC) | Aluminium and Hi-Chrome |
Bearing Lubrication | Grease |
Maximum immersion depth | 20m |
Maximum Working Pressure | upto 4.2 bar |
- Wear resistant closed/semi open impeller in Hi-chrome alloy steel
- Ergonomically designed for easy handling
- Dual mechanical seal provides additional protection to motor
- Mine tailings
- Power plant ash
- River and lagoon silt
- Steel slag
- Rolling mill scale
- Sewage and waste water
- Flood control
- Contruction dewatering
